Preheating & heat treatment machine and accessories
50kva UK type PWHT machine,post weld heat treatment machine
Our PWHT machines are far infrared heating equipment with PID system.
Their main applications are pipeline heating, pre-welding heating, post-welding heat treatment, stress relief,, annealing,ect.
1. Pre-heating: Straight seam weld, longitudinal, circumferential weld, thick steel plate etc.
2. Post-welding heat treatment: tank, boiler or other metal jobs
3. Heating: mold heating, shipboard, zinc bath, large& irregular metal parts
4. Pipeline heating: pipeline oil, pipeline gas, pipeline water, pipeline petrochemical and other pipeline material
The using fields involved are petrochemical, oil and gas pipelines, aerospace, shipbuilding, steel, Hydropower construction ,
tanks, boilers, vessels, pressure vessels, cylinders, metal structure, spatial structure, railway bridges, electricity water, mine construction,
vehicle manufacturing, nuclear power, mining, plastics processing, energy saving process, screw barrel industries,ect.
TDWK-D-50kva 6 channels
60V Output Voltage
Japanese CHINO EH3000 recorder
50 kva rated power;
it can take 18 pieces of 2.7 kw 60V heaters working at
the same time at most;
There will be 6 temperature control channels，the power of each channel is 8.1kva，which can match 3 piece of 2.7kw 60kw heaters at most.
Input voltage：415V/380V/400V/440V/480V 3phase 50Hz/60Hz AC.
